Z Series
Optex FA
Serie OBSOLETA, ha sido reemplazada por la serie Z3 Haga click para redireccionar a la nueva serie.
Todos los sensores fotoeléctricos son de tamaño compacto.
La serie ZR-Q son ideales para detección de objetos transparentes, como botellas de plástico, film, etc.
La serie ZR-X/QX son de haz coaxial, permite sensar a través de agujeros pequeños.
La BGS-Z ofrece gran performance en un reducido tamaño.
Son sensores robustos, soportan 100G de shock y tienen grado IP67
Siete tipos diferentes de sensores para la máxima flexibilidad en cualquier aplicación.
Especificaciones
| Model | Thru-beam | Polarized retro reflective |
Diffuse-reflective | Convergent | Divergent | Glass Detection | |
| Cable type | NPN | ZT-1200N | ZR-350N | ZD-70N | ZD-L09N | ZD-W20N | ZR-Q200N |
| PNP | ZT-1200P | ZR-350P | ZD-70P | ZD-L09P | ZD-W20P | ZR-Q200P | |
| M8 Connector type | NPN | ZT-1200CN | ZR-350CN | ZD-70CN | ZD-L09CN | ZD-W20CN | ZR-Q200CN |
| PNP | ZT-1200CP | ZR-350CP | ZD-70CP | ZD-L09CP | ZD-W20CP | ZR-Q200CP | |
| Sensing distance | 12 m | 3.5m (v-61 ref) | 70 cm | 1-9 cm | 1-200mm | 2 m (V61 ref) | |
| Response time | 0.5 msec | ||||||
| Spot size | 350mm@3.5m | 100 mm@70cm | 12mm@9cm | 30mm@50mm | 300mm@2m | ||
| Operating mode | Light on/dark On selectable | ||||||
| Hysteresis | NIL | 20%max | 10%max | 20%max | NIL | ||
| Light source | Red light | ||||||
| Sensitivity adjustment | 1 turn trimmer (240 º) | ||||||
| Control output | NPN or PNP open collector, 100mA max /30VDC | ||||||
| Supply voltage | DC 10-30V 10% incl. ripple | ||||||
| Power consumption | 20mA max | ||||||
| LED indicator | Dual indicator (output: orange, stable: green) | ||||||
| Protection category | IP67 | ||||||
| Shock resistance | 100G (1000m/s2) | ||||||
| Environmental illuminance | Sunlight: 10000 lux mas, incandescent lamp: 3000 lux max | ||||||
| Operating temp/humidity | -25 to 55ºC / 35 to 85% RH | ||||||
| Materials | ABS with glass fiber (case), PMMA (Lens) | ||||||
| Model | Retro Reflective for Transparent | ||
|---|---|---|---|
| Coaxial Beam | |||
| 2m Cable | M8QD 4pin | ||
| Type | NPN | ZR-QX200N | ZR-QX200CN4 |
| PNP | ZR-QX200P | ZR-QX200CP4 | |
| Sensing distance | 0 - 2 meter (P250F reflector) | ||
| Response time | 0.5 msec | ||
| Spot size | φ60mm / at 2m | ||
| Operating mode | Light On / Dark On selectable | ||
| LED Indicator | Output : orange | ||
| Light source | Red LED | ||
| Sensitivity adjustment | 1-turn pot. | ||
| Control output | NPN or PNP open collector, 100mA max / DC30V | ||
| Supply voltage | DC 10 - 30V, including 10% ripple | ||
| Power consumption | 20mA max | ||
| Protection category | IP 67 | ||
| Vibration resistance | 10 to 55 Hz; double amplitude 1.5 mm; 2 hours in each of the X,Y, and Z directions | ||
| Shock resistance | Approximately 100 G (1000 m/s2), 3 times in each of the X, Y, and Z directions | ||
| Environmental illuminance | Sunlight : 10,000 lux max., Incandescent lamp : 3,000 lux max | ||
| Operating temp/humidity | -25 to 55?/ 35 to 85% RH | ||
| Materials | ABS(Case), PMMA(Lens) | ||
